Detector/Conveyor belt metal detector for cement, limestone, coal

FOB Reference Price:Get Latest Price
US $500-2,000 / Sets | 1 Set/Sets Detector/Conveyor belt metal detector for cement, limestone, (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
JuPai
Model Number:
GJT-B
Type:
Conveyor belt metal detector
Adaptive belt width:
500~2000 mm
Adaptive belt speed:
0.8~2.5 m/s
Detecting range:
Iron, aluminum, copper, stainless steel, manganese steel, etc
Detecting sensibility:
15~50 mm
Power supply:
220V±10%, 50/60Hz
name:
Detector/Conveyor belt metal detector for cement, limestone, coal
Supply Ability
Supply Ability:
30 Set/Sets per Month Detector/Conveyor belt metal detector for cement, limestone
Packaging & Delivery
Packaging Details
Export packing, each packed in a wooden case, or as per customer's requests.
Detector/Conveyor belt metal detector for cement, limestone, coal
Port
Qingdao, Shanghai, Tianjin, etc
Lead Time :
Shipped in 7 days after payment

Detector/Conveyor belt metal detector for cement, limestone, coal

 Product Introduction

 GJT-B series conveyor belt metal detector is the latest product in metal detecting field. In circuit design, this product adopts digital phase shifting and related detecting technologies, which are the latest metal detecting technologies. With stable performance, high detecting sensibility and strong disturbance resisting ability, GJT-B series conveyor belt metal detector is widely used together with belt conveyors for metal detection in thermal power, cement, paper, mining, forestry, environment protection, building materials and other industries.

 Working principle

 When the metal gets into the sensor electromagnetic field, some changing signals are generated, and the metal detector can detect them. Then the metal detector can process the signals with electronic technology and drive the executing device (switches of motor) to stop the belt conveyor so that the operator can pick the harmful metal out manually.

Timing function: The electric relay will be delayed released after actuation, and the time will be between 1~10 seconds.
Output control: One pair of the connection points of the electric relay is normally open, while the other pair is normally closed.

Detector/Conveyor belt metal detector for cement, limestone, coal



 Product Parameters



Model No.

Adaptive belt width

(mm)

Power

(W)

Adaptive belt speed

(m/s)

Power supply

Detecting range

Detecting sensibility

(mm)

Weight

(kg)

GJT-5B

500

40

0.8~2.5

220V±10%,

50/60Hz

Iron, aluminum, copper, stainless steel, manganese steel, chrome steel, etc.

15

105

GJT-6B

650

40

18

125

GJT-8B

800

50

20

160

GJT-10B

1000

50

25

190

GJT-12B

1200

50

30

255

GJT-14B

1400

60

35

290

GJT-16B

1600

60

40

350

GJT-18B

1800

65

50

430

GJT-20B

2000

70

50

480

 Packaging & Shipping

20160811_155208_resized.jpg20160811_151825_resized.jpg20160811_153806_resized.jpg 1235
